EasySyn is the reactor system for organic or aqueous syntheses. It ensures safe and reproducible chemical reactions on the way from laboratory to pilot scale.
【此处内容编辑，像word排版一样简单，文字、图片、视频等，都支持。】
EasySyn Advanced includes the LT 5.40 draining set. With its special valves, it enables fast and clean draining of the tempering fluid from the double jacket and easy replacement of the reactor vessel.
Ergonomically designed stand system for quick and easy replacement of the reactor vessels and adjustment of the working height to your body size.
DN 100 vessel clamp for holding the reactor vessel
Double-walled 1000 ml reaction vessel made of chemically resistant borosilicate 3.3 glass with bottom discharge valve
Spring-loaded valve spindle of the drain valve to prevent glass breakage
Reactor lid with various openings (1 x NS 29/32 center glass joint, 2 x NS 29/32, 1 x NS 14/23) for flexible adaptation to the desired application
DN 100 clamp ring and DN 100 FEP-coated O-ring to ensure chemical resistance
Powerful overhead stirrer EUROSTAR 100 control with 100 Ncm, including keyless chuck for easy and fast mounting of the stirring tool
Additional functions such as timer, overload protection and temperature measurement integrated in the overhead stirrer
PTFE-coated propeller stirrer for optimum mixing and chemical resistance
High-quality stirrer guide for vacuum operation up to 3 mbar
Drainage set LT 5.40 with valves and temperature control hoses for easy draining of the double-walled reactor vessel and for fast changing of the reactor vessels
RS 232 interface on the stirrer for external control using our lab automation software labworldsoft® 6, available as an accessory.
Further reactor vessels (with and without bottom discharge), reactor covers, stirring tools, temperature sensors, circulators, laboratory automation and much more can be found in the " Accessories" section.
To complete your system, you get all the complementary components from a single source: overhead stirrers, circulators, vacuum pumps and controllers, sensors and automation software. All from IKA and all perfectly matched to each other.
Would you like your own desired configuration? Or do you need an offer? You are welcome to contact our sales team.
Note: The scope of delivery does not include temperature hoses for connecting a thermostat.
SY stand
SY 1000 D Reactor vessel
SY clamp 100
SY clamp ring 100
SY O-ring 100
SY 100.1 Reactor lid
R 4011 SY Propeller stirrer
EUROSTAR 100 control
SY guide
R 60 Keyless chuck
LT 5.40 Draining set
